List of YT28 spare parts
Part NO. | Code | Spare parts | Quantity |
1 | YT28-1.02 | ratchet | 1 |
2 | YT28-1.03 | valve chest | 1 |
3 | YT28-1.05 | valve cover | 1 |
4 | YT28-1.08 | rifle nut | 1 |
5 | YT28-1.10 | piston | 1 |
6 | YT28-1.11a | cylinder | 1 |
7 | YT28-1.12a | guide sleeve | 1 |
8 | YT28-1.13 | muffle | 1 |
9 | YT28-1.14 | liner sleeve | 1 |
10 | YT24-1.04 | valve | 1 |
11 | YT24-1.06 | setting pin | 1 |
12 | YT24-1.07 | ratchet pawl | 4 |
13 | YT24-1.09 | rifle bar | 1 |
14 | YT24-1.15 | crowned spring | 4 |
15 | YT28-2.01a | front head | 1 |
16 | YT28-2.02a | rotational sleeve | 1 |
17 | YT24-2.03 | shank sleeve | 1 |
18 | YT28-2.12 | spring pad | 2 |
19 | YT28-2.05a | yolk spring | 2 |
20 | YT24-2.06 | yolk bolt | 2 |
21 | YT24-2.07 | yolk | 1 |
22 | YT28-2.09 | spline nut | 1 |
23 | GB889 M16 | hex locking nut | 2 |
24 | YT28-3.02 | side bolt | 2 |
25 | YT28-3.03a | control valve | 1 |
26 | YT28-3.04 | water tube | 1 |
27 | YT28-3.05 | air tube | 1 |
28 | YT28-3.07 | big seal set | 1 |
29 | YT28-3.08a | back head | 1 |
30 | YT25-3.13 | ring | 2 |
31 | YT28-3.14 | pressure regulation valve | 1 |
32 | YT28-3.21 | control handle | 1 |
33 | YT28-3.27 | left handle | 1 |
34 | YT24-3.01 | flexible ring | 1 |
35 | YT24-3.06 | small seal set | 2 |
36 | YT25-3.09 | side bolt nut | 2 |
37 | YT24-3.10 | steel ring | 1 |
38 | YT28-3.11 | air pipe swivel | 1 |
39 | YT24-3.12 | trigger | 1 |
40 | YT24-3.15 | change over valve | 1 |
41 | YT24-3.16 | spring | 1 |
42 | YT28-3.18 | water pipe swivel | 1 |
43 | YT24-3.19 | steel ring | 1 |
44 | YT24-2.06 | fixing pin | 1 |
45 | YT28-2.05 | water valve set | 1 |
46 | YT24-3.22 | steel ring | 1 |
47 | YT24-3.25a | spring cap | 1 |
48 | YT24-3.26 | water valve | 1 |
49 | YT24-3.28 | right handle | 1 |
50 | YT24-3.29 | rubber handle | 1 |
51 | YT24-3.30 | seal ring | 1 |
52 | YT25-3.06 | spring | 1 |
53 | YT25-3.09 | water tube set | 1 |
54 | YT25-3.13 | rubber pad | 1 |
55 | YT25-3.14 | air tube pad | 1 |
56 | YT25-3.20 | spring | 1 |
57 | YT25-3.21 | setting pin | 1 |
58 | YT24-3.24 | ring seal | 1 |
59 | YT25-3.35 | pad | 1 |
60 | 8*1.9 GB1235-76 | O-ring | 1 |
61 | 22*2.4 GB1235-76 | O-ring | 1 |
62 | 25*2.4 GB1235-76 | O-ring | 1 |
63 | 36*3.5 GB1235-76 | O-ring | 3 |
64 | D100 ZBJ15001-87 | hoop | 1 |
65 | GB879 8*24 | flexing pin | 1 |
66 | GB93 10 | standard spring pad | 1 |
67 | GB6172 M10 | hex thin nut | 1 |
